Refurbished AGM ASP TM25-384 THERMAL IMAGING MONOCULAR

PART NO.: 3093451006AS21

€ 1,120.00 € 1,493.00

Other Models ARE Also Available:

Package Includes

Downloads

Description and Features

limited quantity 3 pcs
The Asp TM-384 handheld observational thermal monocular is equipped with a 384 × 288 infrared detector and a 1024×768 OLED display. The high-sensitivity built-in thermal detector provides you with clear view even in total darkness. It supports functions of observation, hot spot tracking, distance measurement, Wi-Fi hot spot, and so on. The monocular is mainly applied to scenarios such as patrolling, law enforcement, searching and rescuing, drug enforcement, anti-smuggling, criminal seizing, hiking, travel, and hunting, etc.

Please contact us for additional information info@agmglobalvision.eu

FUNCTIONS
Distance Measurement: The device realizes distance measurement function after marking the top and bottom of target, and input the target height.
Hot Spot Mark: The device detects and marks the hot spot of highest temperature.
Wi-Fi & Hot Spot: Device can capture snapshots, record videos, and set parameters via APP after being connected to your phone.
Mode Switch: Device supports pallet switch and distance measurement.
Storage: Built-in memory module supports video recording/snapshot capturing.
Digital Zoom: Device supports 2× and 4x digital zoom.

384 × 288 resolution, high sensitivity detector
Adaptive AGC, DDE, 3D DNR, NETD less than 35 mk (@25°C), F#=1.0
1024 × 768 resolution 0.39-inch OLED display
Built-in rechargeable Li-ion battery
Up to five hours continuous running (with Wi-Fi hot spot function off)
Wi-Fi hot spot
6 months warranty
free shipping within EU

SPECIFICATIONS

Image sensor:	Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution:	384*288
Detector type	17um
Recognition Range	(Vehicles: 1.4×4.0m) - 564m (Humans: 1.8×0.5m) - 184m
Detection Range	(Vehicles: 1.4×4.0m) - 2255m (Humans: 1.8×0.5m) - 735m
Identification Range	(Vehicles: 1.4×4.0m) - 282m (Humans: 1.8×0.5m) - 92m
Diopter Adjustement	-5 to +3 dpt
Response Wavebond:	8um to 14um
NETD:	< 35mk(@25°C,F#=1.0)
Lens (focal length):	25mm
Optical magnification	1.7x
Field of View:	14.88° x 11.19°
F number:	1.0
Digital Zoom:	1x, 2x
Palettes:	Black hot White hot Red hot Fusion
Monitor:	0.39-inch, OLED, 1024 × 768
Hot Track:	Yes
Storage:	Built-in memory module (16GB)
Record Video:	Support on-board video recording
Capture Snapshot:	Yes
Wi-Fi:	Yes
Battery Type	Lithium Battery
Battery Operating Time:	Up to 5 hours continuous running
Battery Capacity Display:	Yes
Power:	5V DC/2A, 2W
Working Temperature/ Humidity:	-30 °C to 55 °C (-22 °F to 131 °F)
Protection Level:	IP67
Dimensions:	189 mm × 74 mm × 66 mm (7.9″ × 2.91″ × 2.60″)
Weight:	460 g (1.01 lb)

optional equipment

AGM Solar Power Bank

PART NO.: 6308EPB1

AGM Power Bank, User Manual, Carrying case, USB Cable Type-C. Micro USB Cable This universal power bank / QI charger aquipes with a solar panel that captures energy of day light and transforms it into charging power for your devices. You can charge anything devices because it has built-in Micro-USB, USB-C and Lightingcabels, and QI wireless technology. Thanks to its rugged shock-proof housing, rain-proof design, and 10000mAh battery capacity, it’s perfect for long extreme hikes. Just attach this rain-resistant solar power bank to your backpack and your gadgets will always have extra power.

€ 49.00
